A tomato pulper is a core piece of equipment specifically designed for tomato processing. Its main function is to convert pre-treated tomatoes into tomato pulp, while effectively separating the peel, seeds, and other coarse fibrous impurities. In the industrial production of tomato sauce, tomato puree, tomato juice, and related food products, the tomato pulper is a crucial piece of equipment.
This equipment combines pulping and separation functions. It can complete both coarse pulp processing and fine pulping in continuous operation, making it an important piece of equipment in a tomato sauce production line. The pulper can be connected to upstream equipment such as washing, crushing, and preheating systems, as well as downstream evaporation, concentration, and sterilization systems. Get a free quote! WhatsApp/Phone: +86 13838385752.
During operation, the tomato pulper uses a high-speed rotating main shaft to drive the pulping blades, continuously impacting, squeezing, and shearing the tomato material entering the equipment.
First, washed and pre-treated tomatoes are fed into the pulping chamber. At a stable main shaft speed of 860 rpm, the machine breaks the tomato material into coarse pulp. At the same time, centrifugal force and mechanical action separate larger fibrous materials such as peels and seeds. The tomato pulp then passes through a 0.6 mm filter screen to form tomato puree, while peels, pulp residues, and seeds that cannot pass through the screen discharge through a separate outlet, achieving effective separation.
Features of Tomato Pulper Machine
Processing Capacity
This tomato pulper has a processing capacity of 1–1.5 tons/hour. It can meet the continuous production needs of small and medium-sized food processing plants, increasing overall capacity while ensuring quality.
Pulping Effect
With a 0.6mm filter screen, the equipment effectively separates the peel, seeds, and coarse fibers to obtain tomato pulp. The equipment is suitable for products requiring high-quality taste and stability.
Material
The entire machine is made of SUS304 stainless steel. Parts in contact with materials meet food hygiene standards, possessing good corrosion resistance and easy cleaning, suitable for long-term processing of acidic tomatoes.
Footage
The overall dimensions of the equipment are 1500×680×1560mm. The rational structural layout facilitates installation and use in existing production workshops.
Power Configuration
Equipped with a 5.5kW motor, it achieves energy consumption control while ensuring pulping efficiency, helping to reduce operating costs.
Compared to traditional manual labor or simple equipment, the fruit pulper machine allows for precise control over the fineness of the pulp. This design results in a smoother texture and more uniform color in the tomato pulp, which is beneficial for subsequent processing.
Cost
The equipment can operate continuously, with a single machine completing both the pulping and separation processes. This reduces manual labor and increases the automation level of the production line.
Raw Material Utilization
Through efficient separation technology, the equipment retains usable pulp while ensuring effective separation. This reduces waste and improves economic efficiency.
Scope
In addition to tomatoes, it can also be used for pulping other fruits and vegetables, demonstrating versatility and expandability.
FAQ
What size factory is this tomato pulper suitable for?
This equipment suits small and medium-sized tomato processing enterprises or pilot production lines and also serves as a pulping unit in large production lines.
Is the equipment easy to maintain?
The entire machine is made of SUS304 stainless steel. Its reasonable structural design facilitates disassembly and cleaning, meeting food processing hygiene requirements.
Can it be connected to other equipment in a production line?
Yes. This tomato puller machine can form a complete production line with a washing machine, crusher, preheater, and subsequent processing equipment.
We are a large-scale machinery and equipment company with 20 years of experience. We have a professional R&D team that keeps up-to-date with the latest technologies. Our after-sales team provides 24-hour support.
If you are interested in a tomato pulping machine, please feel free to contact us! The pulping machine can be integrated into our tomato sauce production line. Get a quote!
