The automatic helmet cleaning machine is an intelligent device that integrates cleaning, disinfection, and drying functions. It features automatic disinfectant spraying, PTC heating drying, and fragrance spraying. The machine effectively cleans the inside of helmets, removing odors, bacteria, and moisture. Inquiries are welcome! WhatsApp/Phone: +86 13838385752.


Parameters of Helmet Cleaning Machine
| Model | FL – SD01 | FL – SD02 |
|---|---|---|
| Boundary Dimensions | 650mm * 2025mm * 600mm | 660mm * 1966mm * 600mm |
| Voltage / Frequency | 220V / 50Hz | 220V / 50Hz |
| Rated Power | 2100W | 2100W |
| Operation Interface | 15.6″ Touch Screen | 12.1″ Touch Screen |
| Networking Mode | Wi-Fi / 4G | Wi-Fi / 4G |
| Payment System | Card Reader, Coin Reader | Card Reader, Coin Reader |
| Disinfection Method | Steam / UV Lamp | Steam / UV Lamp |
| Drying Method | PTC Heating | PTC Heating |
| Disinfection Volume / Quantity | 5L / 1 | 5L / 1 |
| Perfume Bottle Capacity | 450ml | 450ml |
| Number of Perfume Bottles | 4 | 4 |
| Number of Doors | 2 Doors | 1 Door |
| Quantity of Perfume | Four Kinds | Four Kinds |
| Door Closing Mode | Magnetic Lock | Magnetic Lock |
Automatic Helmet Washing Machine’s Workflow

- The user places the helmet inside the device.
- Door is closed.
- The system automatically sprays disinfectant.
- PTC heating system activates to dry the interior.
- After completion, fragrance is automatically sprayed.
- The system ends and prompts the user to remove the helmet.
Application Scenarios of Automatic Helmet Cleaning Machine
- Park Areas: In large urban parks or cycling-themed parks, visitors frequently ride electric bikes or bicycles. Installing helmet washing machines ensures that every visitor uses a clean, odor-free helmet. This equipment improves service quality and visitor satisfaction.
- Delivery Rider Stations: Delivery riders use helmets daily. Automatic helmet cleaning machines can disinfect them regularly, ensuring their health and reducing discomfort caused by helmet odors.
- Motorcycle Rental Shops: Motorcycle rental businesses in tourist cities need to standardize helmet handling. Operations staff can use helmet cleaning machines to quickly complete the disinfection and drying process, improving helmet turnover efficiency.
- Shopping Malls and Office Buildings: Shopping malls can enhance their service level by offering helmet cleaning services. Office building management can provide value-added services to cyclists by installing automatic helmet cleaning machines.


Helmet Cleaning Machine Features
PTC Heating and Drying System
Both helmet cleaning machines utilize PTC heating technology. PTC heating features constant temperature, safety, and energy efficiency. Once started, the system heats up to dry the inside of the helmet, preventing bacterial growth caused by a damp environment.
Disinfection System
The equipment is equipped with a 5L disinfectant storage capacity. An automatic spraying system covers the inside of the helmet with disinfectant, effectively removing bacteria and odors.
Fragrance Options
Each machine comes with four 450ml fragrance bottles, supporting four different scents. Operators can choose the fragrance according to user preferences. The fragrance system not only improves helmet odor but also serves as a brand-specific service, enhancing user recall.
Automatic Operation Process
After the user places the helmet inside, the machine automatically completes the process. No manual intervention is required, improving operational efficiency.

Advantages of Smart Helmet Cleaning Machine
Additional Revenue
Operators can integrate helmet cleaning machines with rental systems or offer them as a paid value-added service. Operators can set up a pay-per-use model for profit.
Enclosed Structure
The equipment employs an enclosed cabin structure. The system completes the entire process within a separate space and avoids interference from the external environment. This design is suitable for public places, maintaining environmental hygiene.
Service Level
Providing professional helmet cleaning machines in public places not only solves hygiene issues but also demonstrates the brand’s attitude.
FAQ
The 5L capacity supports multiple cycles. The specific replacement frequency depends on the number of uses.
We can provide customization services for appearance, brand logo, voltage, etc., according to customer needs.
If customer traffic is moderate, a single-door model is sufficient. If daily usage is high, a double-door model is recommended.
About Foodline Machinery
- CE Certification
- Export Experience
- R&D Team
- After-Sales Service
In addition, we also sell snack and beverage vending machines. We can also offer this equipment as a value-added service. Please inquire for a quote! WhatsApp/Phone: +86 13838385752.
